| Product Attribute | Attribute Value |
|---|---|
| Air Flow | 106 CFM (3002 L/Min.) |
| Approximate Thickness | 1.5 In. (38 mm) |
| Bearing Type | Ball |
| Configuration | Square |
| Dimensions | 4.7 x 4.7 x 1.5 In. (119 x 119 x 38 mm) |
| Fan Type | AC |
| Frequency | 50;60 Hz |
| Material | Metal |
| Maximum Operating Temperature | 90 C |
| Noise Level | 51 dBA |
| Power Rating | 18 W |
| Primary Type | Fan |
| Rotation | CW |
| Series | |
| Size | 4.7 x 1.5 (119 x 38) In. (mm) |
| Size, Approximate | 4.7 x 4.7 In. (119 x 119 mm) |
| Termination | Terminals |
| Type | Square |
| Voltage Rating | 115 VAC |
| Weight | 1.19 Lbs. |
Overview
Clockwise rotation viewed from rotor. Electrical connection with LZ120 plug and cord set (sold separately), or soldered.
Features:
